RC Car & Truck Guides — Upgrades, Repairs & Troubleshooting

A brushed motor uses physical carbon brushes that wear down and need replacing. Brushless motors use sensored or sensorless electronic commutation instead, which means less friction, higher efficiency and a longer service life, but it requires an ESC built for brushless timing rather than a brushed-only unit.

Scale is printed on the box or chassis (1/8, 1/10, 1/16, and so on) and refers to the ratio between the model and a full-size vehicle. A 1/8 scale truck runs roughly 17-18 inches long, while a 1/16 scale truck is closer to 10 inches, and the two use entirely different battery and part standards.

Most crawler builds run heavier oil, in the 40-50 weight range, than a bash-oriented truck would use, because slow, controlled articulation over obstacles needs more damping resistance than high-speed suspension compression does.

For anyone driving it regularly, yes. A matched brushless motor and ESC combo adds meaningful top speed and run time over the stock brushed system, though it also increases stress on the drivetrain, so upgraded diff gears and driveshafts are worth doing at the same time.

Check resting voltage with a multimeter first. A NiMH or LiPo pack that won't hold voltage under load, feels swollen, or shows a voltage imbalance between cells on a balance-charger readout is failing and should be retired rather than pushed further.

A stock-class 2WD short course truck with a brushed 550 motor and a basic 2S LiPo is a reasonable starting point. Most drivers upgrade to brushless and a stiffer set of shocks once they've outgrown the stock power band.

Yes. 2WD and 4WD Traxxas platforms use different diffs, driveshafts and in some cases different motor mounts, so parts aren't interchangeable across drivetrain layouts even within the same model line.

It varies by kV rating and gearing, but a well-matched brushless swap on a Slash-class truck commonly adds somewhere in the range of 15-25 mph over the stock brushed setup, depending on battery cell count and pinion size.

Elevation changes, off-camber sections and articulation-testing gaps, such as stacked pallets, angled ramps and loose rock piles, test a crawler's suspension travel and traction far more than a flat, open driveway does.

Only if the connector, voltage (cell count) and physical size match the battery tray. A 3S pack sized for an E-Maxx won't necessarily fit or wire into a Slash without an adapter, and running the wrong cell count risks damaging the ESC.
